DrayTek VigorSwitch P2500 50-Port PoE+ Gigabit Switch
£635.00 ex VAT
Physical Interfaces
- 44 10/100/1000BaseT Ethernet Ports (RJ-45 IEEE 802.3/3u/ab)
- 4 Selectable Ports (Nos. 45-48), use as either:
- 10/100/1000BaseT (Gigabit) Ethernet or
- SFP (802.3z)
- 2 SFP Ports (100Mbps / 1Gbps)
- Console Port (RJ-45 physical, RS-232 electrical)
PoE Specification
- 44-ports 802.3af & 802.3at (High Power) PoE PSE
- 405 Watts Total Power Budget for PoE
- Auto Detection of Powered Device (PD) and Consumption Levels
- Per Port PoE Status LED Indicators
- Alert LED for high PoE Usage
- Port Power Consumption Monitoring via Web Interface & CLI
- PoE PD Scheduling (per port)
- PoE PD Priority (per port)
- PoE PD Status / Ping monitoring – restart PoE PD port on no connectivity (per port)
- Circuit Protection to Prevent Power Interference between Ports
Out of stock
DrayTek VigorSwitch P2500 50-Port PoE+ Gigabit Switch
Designed for Centralised Management
Can be configured and monitored instantly through both the VigorACS cloud management platform and/or, a DrayTek Vigor router’s central switch management.
Benefits: Saves time and money. Easily provision, monitor and manage remote sites without on-site IT or dedicated staff.
Security
DHCP Snooping: Limit DHCP server responses to only a specified port.
IP Source Guard: Protects against address spoofing.
Access Control List: Controls which packet types (IPv4, IPv6 & MAC) should pass between ports on the switch.
Energy-Efficient PoE
Smart power management & IEEE 802.3az compliant. If a non-PoE device is connected, that port’s PoE power is turned off to avoid any potential damage to non-compliant devices.
Benefits: Reduces power consumption.
405W PoE Power Budget
Provides ample power through Ethernet, to each of its 44 PoE / PoE+ enabled Gigabit LAN ports.
Benefits: It can easily power a large number of IP cameras, IP phones, wireless APs and other PoE devices.
Voice VLAN & Surveillance VLAN
Automatically assign VLANs and QoS configuration to devices with matching MAC address OUI upon connection to the switch.
Benefits: Reduces broadcast traffic and allow more control when implementing security policies.
Hardware Monitoring
It monitors and controls the switch’s temperature, voltages and fan status. Email notification alerts integrated for power loss, downtime or configuration changes.
Benefits: Prevents network failure. Ensures high availability.
VigorSwitch P2500 – 50 Port Gigabit Switch with 44 PoE+ Ports
The VigorSwitch P2500 is a high-performance, Managed Gigabit Ethernet switch with PoE+ (Power over Ethernet).
The 405 watt PoE power budget provides ample power through Ethernet, to each of its 44 PoE / PoE+ enabled Gigabit LAN ports. Supporting up to 30 watts per port, it can easily power a large number of IP cameras, IP phones, wireless APs and other PoE devices.
Use the 4 switchable SFP/RJ-45 ports and 2 dedicated SFP module slots to link with additional switches using link aggregation, or plug in a suitable SFP module to use optical Fibre as an Ethernet uplink.
Designed for centralised management, the VigorSwitch P2500 can be provisioned and monitored through both the VigorACS management platform and/or, a DrayTek Vigor router’s Central Switch Management. Easily provision the VLAN configuration through the router and clone switch configurations. Drastically reduce the setup time required for a complex network, with VLANs spanning multiple switches.
